Specifications: Model: f6m 128g Transport Protocol: AHCI Interface Type: MSATA Item Condition: New Controller: SMI2258XT/S11 Cooling Fin: No RGB: No Size: mSATA Bus Type: SATA III Application: Desktop Application: Laptop Application: Server Model Number: F6M Nand Flash Type: TLC Certification: CE Certification: FCC Certification: RoHS Package: Yes Type: Internal Style: SSD Size: 3x5cm Support: OEM/ODM/Wholesale price/ dropshipping Capacity: 128GB, 256GB, 512GB, 1TB Bad Block Management: Auto Bad Block Management in the system Warranty: 3 years
- mSATA SATA III TLC NAND Internal Solid State Drive. - mSATA Platform for PC and laptap. -SATA 6.0 Gb/s Interface.Max Read Speed: 550 MB/s, Max Write Speed: 500MB/s, performance may vary based on system hardware & configuration. - WARRANTY - 3 years warranty provided by us.
1, Our test result is base on SATA 3 interface, SATA 3 sata cable, desktop and SSD empty status, different desktop and software (include software version), the result may be different.
2, Difference between SATA 1, SATA 2 and SATA 3
SATA 1 (revision 1.x) interface, formally known as SATA 1.5Gb/s, it is the first generation SATA interface running at 1.5 Gb/s. Max speed 150MB/s.
SATA 2 (revision 2.x) interface, formally known as SATA 3Gb/s, it is the second generation SATA interface running at 3.0 Gb/s. Max speed 300MB/s.
SATA 3 (revision 3.x) interface, formally known as SATA 6Gb/s, it is the third generation SATA interface running at 6.0Gb/s. Max speed 600MB/s. This interface is backwards compatible with SATA 3 Gb/s interface.
If SATA 3 SSD tests the speed on SATA 2 interface and sata cable, the result will be inaccurate.
Q: Can I use for laptops and desktops? A: Our mSATA SSD supports motherboard with mSATA SATA Interface
Q: Why the capacity display from PC is smaller than the original capacity? A: Actual usable space may be less than the total storage capacity listed due to Decimal measurement used to represent usable capacity of the SSD. Actual capacity calculation: Total storage × 0.93 Factory default setting: 1GB=1000MB=1000000KB=1000000000B Computer system setting: 1GB=1024MB=1048576KB=1073741824B Example: 360GB SSD Factory capacity: 360 × 1000 × 1000 × 1000=360000000000B Transfer to PC display actual capacity: 360000000000B/1024/1024/1024=335G Fast calculation: 360G × 0.93=335G
Q: The working temperature? A: 0-70 celsius
Q: What's in the package? A: SSD and the manual. (Without the screws)
Q: Why choose KingFast? A: We are professional SSD manufacturer with 12 years of quality management experience. You can get the lowest price and the best service. And we provide 3 years warranty.
Before you use:Open Start. Search for "Create and format hard disk partitions" and click the top result to open the Disk Management console. Then you can find our SSD, please do the format and partition.
